Incorporation since 2002. I-Tech Sensors has been setting new benchmarks with innovating solutions for sanitary automatic sensors and other industries. Providing the best quality with up to date technology solutions has kept us competitive in this fast-moving industry. With our intelligent innovating ideas, we are committed to delivering beyond expectations to our customers.
Our Mission
Providing customized solutions with our expertise to our customers. We are committed to delivering beyond expectations by setting new benchmarks with innovative solutions.
Our Solution
With more than 20 years of local and overseas experiences, our R&D Engineers are equipped with the KNOW-HOW to all aspects.
Our Services
We are committed to provide low cost, high-quality parts, workmanship, design and end products.
Featured Products
IT – 386 DR
Powered with compact opto sensor electronic with advance comprehensive
programming to meet ultimate requirements. The sensing electronic is design to
perform under all conditions that may arise. Enclosed with quality 304 stainless steel
grade casing
| General specification | |
|---|---|
| Brand | : iTech |
| Size | : Ø88mm x 80 mm |
| Inlet pipe | : G 1/2” |
| Outlet flush pipe | : Ø32mm |
| Operating Time | : Min. 7 seconds |
| Operating Temp | : 0 – 40°C |
| Discharge Volume | : 1.0 L/Flush |
| Operating pressure | :1 to 8 Bars |
| Input Voltage | : 230 VAC 50Hz |
| Battery Operated | |
| Battery size | : 1 x CR-P2 6V 1300mAh |
| Battery Life | : Min. 2 yrs 150cycles / day |
| Universal Electronic | |
|
• Low power consumption. • Multi voltage : 6, 9 and 12 VDC • 100% waterproofing in the electronics and cables. Infra-red sensitivity is automatically adjusted to ambient. • When low voltage is detected, the electronic will auto cut-off all cartridge valve function to prevent continuous water flow. |
|
| Cartriage valve | |
|
• low power consumption. (Nominal power 0.5 -1.2W) • screw-in design. • built-in strainer/filter. • built-in self cleaning ability. |
|
| Description | |
| Powered with compact opto sensor electronic with advance comprehensive programming to meet ultimate requirements. The sensing electronic is design to perform under all conditions that may arise. Advance compact cartridge valves (differs from conventional solenoid valve) is incorporated into the flushing systems. Cartridge Valve with its unique compact design, it have made design more durable with the following features. Enclosed with quality 304 stainless steel grade casing, frame and front cover. | |
| [pc-pvt-content allow="13" warning="1"]Download PDF[/pc-pvt-content] | |
| [pc-logout-box] |
IT – 386 DL
Powered with compact opto sensor electronic with advance comprehensive
programming to meet ultimate requirements. The sensing electronic is design to
perform under all conditions that may arise. Enclosed with quality 304 stainless steel
grade casing
| General specification | |
|---|---|
| Brand | : iTech |
| Size | : 140mm x 140mm |
| Inlet pipe | : G 1/2” |
| Outlet flush pipe | : Ø15mm |
| Operating Time | : 0.1 seconds |
| Operating Temp | : 0 – 40°C |
| Discharge Volume | : 0.8 L/Flush |
| Operating pressure | :1 to 8 Bars |
| Input Voltage | : 230 VAC 50Hz |
| Universal Electronic | |
| • Low power consumption. • Multi voltage : 6, 9 and 12 VDC • 100% waterproofing in the electronics and cables. Infra-red sensitivity is automatically adjusted to ambient. • When low voltage is detected, the electronic will auto cut-off all cartridge valve function to prevent continuous water flow. |
|
| Cartriage valve | |
| • low power consumption. (Nominal power 0.5 -1.2W) • screw-in design. • built-in strainer/filter. • built-in self cleaning ability. |
|
| Description | |
| Powered with compact opto sensor electronic with advance comprehensive programming to meet ultimate requirements. The sensing electronic is design to perform under all conditions that may arise. Advance compact cartridge valves (differs from conventional solenoid valve) is incorporated into the flushing systems. Cartridge Valve with its unique compact design, it have made design more durable with the following features. Enclosed with quality 304 stainless steel grade casing, frame and front cover. | |
| [pc-pvt-content allow="13" warning="1"]Download PDF[/pc-pvt-content] | |
| [pc-logout-box] |
IT – 286CL
Powered with compact opto sensor electronic with advance comprehensive
programming to meet ultimate requirements. The sensing electronic is design to
perform under all conditions that may arise. Enclosed with quality 304 stainless steel
grade casing
| General specification | |
|---|---|
| Brand | : iTech |
| Size | : 200mm x 200 mm |
| Material Used | : Flush valve (Brass) : Frame/Plate (SS304) |
| Input Voltage | : 230 VAC 50Hz |
| Inlet pipe | : G 1” |
| Outlet flush pipe | : Ø32mm |
| Operating Time | : Min. 7 seconds |
| Operating Temp | : 0 – 40°C |
| Discharge Volume | : 4.5 L/Flush |
| Operating pressure | :1 to 8 Bars |
| Universal Electronic | |
|
• Low power consumption. • Multi voltage : 6, 9 and 12 VDC • 100% waterproofing in the electronics and cables. Infra-red sensitivity is automatically adjusted to ambient. • When low voltage is detected, the electronic will auto cut-off all cartridge valve function to prevent continuous water flow. |
|
| Cartriage valve | |
|
• low power consumption. (Nominal power 0.5 -1.2W) • screw-in design. • built-in strainer/filter. • built-in self cleaning ability. |
|
| Description | |
| Powered with compact opto sensor electronic with advance comprehensive programming to meet ultimate requirements. The sensing electronic is design to perform under all conditions that may arise. Advance compact cartridge valves (differs from conventional solenoid valve) is incorporated into the flushing systems. Cartridge Valve with its unique compact design, it have made design more durable with the following features. Enclosed with quality 304 stainless steel grade casing, frame and front cover. | |
| [pc-pvt-content allow="13" warning="1"]Download PDF[/pc-pvt-content] | |
| [pc-logout-box] |
